1300Mbps Dual Frequency Drive-free wireless network card computer notebook external Gigabit wifi receiver
Price section
Price from:
145,764 so'm
Coverage
Drive-free version
Optical Drive Edition
Guaranteed delivery time
If we are 45 days late, you will receive your order for free. More details
Always in touch with you
We will answer any questions every day.
Secure payment in a convenient way
We will accept payment by any card
About the product
Characteristic
- Transmission rate
1300Mbps
- Item No.
RTL8812CU
- Interface Type
USB
- Brand
Neutral
- Model
M-1300FR
- Color
Black
- Product Weight
0.05kg
- Time to market
2023
- Wireless Standards
IEEE 802.11g
IEEE 802.11b
IEEE 802.11n
- Support Agreement
IEEE 802.11ac/a/ B /g/n
- After-sales service
Store Three Guarantees
- Source category
Spot
- Fastest shipping time
1-3 days
- Whether to support one-piece distribution
Support
- Invoice
Invoice Not provided
- Packing List
Machine, blister, color card, CD
- Licensable private label
No
Description
产品说明：
M-1300FR是一款采用最新的11AC双频无线WIFI标准技术结合的网卡，WIFI可同时搜索2.4G和5G频段的网络信号，使用5GHz频道传输数据的低干扰与极佳效能。因应网络数据量的激增，新一代802.11AC无线传输技术，相较现有11n技术，把5GHz的传输速率大幅提升了将近3倍，WIFI最高传输速率2.4G/300Mbps和5G/866Mbps;可以让您以无线方式，享受有线网络般的高速网上冲浪，无论是Online Game或高画质影音，数据传输质量更臻完美，因此激活5GHz频段超速网上冲浪，11AC当然是最佳选择。同时还支持模拟AP热点功能，把有线网络转换成无线信号输出；通过简单的AP模式设置，把网卡当作AP路由来使用，方便用户通过无线网卡来实现多人共享上网。
本无线网卡另集成了无线配置程序，安装使用方便，可以轻松快捷的设置无线客户端，并支持Soft AP功能，方便您快速组建无线局域网。在无线安全方面，它支持WPA/WPA2/WEP/802.1X/WMM加密，让您能快速的实现无线加密，保障无线网络安全。
产品主要特性：
l 支持802.11ac标准的Wi-Fi
l 向下兼容802.11b/g/n无线设备
l 高无线传输速率，双频可选择（2.4GHZ/300Mbps, 5GHZ/867Mbps）
l 支持WPA/WPA2/WEP/802.1X/WMM数据加密
l 兼容Windows XP/Vista/7/8/10, Linx2.6X;Mac OS X等多种操作系统
l 具有很强的抗干扰能力
l 支持最新无线标准
产品规格
|
主芯片 |
RTL8812 |
|
|
无线标准 |
IEEE802.11ac/a/n/g/b |
|
|
接口 |
USB 2.0/3.0可选 |
|
|
天线 |
外置5dBi全向天线 |
|
|
传输距离 |
室内MAX：100米（因环境而异） |
|
|
工作频率 |
2.412~2484GHz/5.15~5.825GHz (根据国家区域) |
|
|
发射功率 |
802.11b (CCK) 11Mbps: 18+/-1dBm |
|
|
802.11g (OFDM) 54Mbps: 15+/-1dBm |
||
|
802.11n(OFDM) 54Mbps: 15+/-1dBm |
||
|
802.11ac（AC80）MCS9：12+/-2dBm |
||
|
EVM |
11b 11Mbps:＜-15db 11g 54Mbps:＜-27db 11ac MCS9：＜-30db |
|
|
接收灵敏度 |
802.11b: -76+/-1dBm；802.11g: -65+/-1dBm |
|
|
802.11n (HT20), -70+/-1dBm；802.11n (HT40), -65+/-1dBm |
||
|
AC80-MCS9：-55+/-1dBm |
||
|
无线传输速率 |
11b: Max 11Mbps,11g:Max 54Mbps ,11n:Max 300Mbps,AC:Max 867Mbps |
|
|
操作系统 |
Windows XP/Vista/7/8/10,Linx2.6X;Mac OS X |
|
|
无线安全支持 |
WPA/WPA2/WEP/802.1X/WMM; |
|
|
物理规格 |
||
|
尺寸 |
175*90*20mm |
|
|
重量 |
48.5g |
|
英文描述：
M-1200FR Wireless AC1200 Dual Band Adapter based on IEEE 802.11ac technology delivers next generation WiFi speeds. With dual band connection, the device effectively avoids interference, ensuring top WiFi speed and reliable connections. The M-1200M is perfect for upgrading your existing laptop and desktop to a Gigabit WiFi Network.
Features:
- Ultra-fast 1200 (867+300)Mbps wireless speed with 802.11ac
- Dual Band connections for lag-free HD video streaming and gaming
- SuperSpeed USB 3.0 port—Up to 10x faster than USB 2.0
- Easy wireless security encryption at a push of the WPS button
- Equipped with a USB docking for flexible deployment
- With dual external 5dBi antennas, wifi signal is enhanced
Specifications:
|
Wireless Standards |
IEEE 802.11ac/a/n/g/b |
|
Interface |
High speed USB3.0 interface |
|
Data Rate |
802.11ac: up to 867Mbps |
|
RF Frequency |
2.4-2.4835GHz; 5.150-5.825GHz |
|
Radio Channel |
1 ~ 14channels |
|
Antenna Type |
2 x External 5dBi Antennas |
|
RF Output Power |
2.4G: 17dbm±2dbm; 5G: 14dbm±2dbm |
|
Modulation |
802.11ac: MU-MIMO |
|
Data Security |
64/128-bit WEP Encryption, WPA, WPS |
|
LED Indicator |
Link/Active |
|
Operating System |
Windows XP/Vista/7/8/8.1/10, Linux, Mac |
|
OperatingTemperature |
0℃to 50℃, 20% ~ 85%RH |
|
Storage Temperature |
-10℃to 65℃, 10% ~ 90%RH |
实物图片
