Sales RYSD type M42M56M64M72M80M105M120 Bolt nut tightening disassembly hydraulic tensioner
Price section
Price from:
1,288,209 so'm
Specifications
RYSD-0
RYSD-1
RYSD-2
RYSD-3
RYSD-4
RYSD-5
RYSD-6
RYSD-7
RYSD-8
RYSD-9
RYSD-10
RYSD-11
RYSD-12
Bolt tensioner specifications are numerous, specific communication
One pump station can synchronize 2 to more
Steel ultra-high pressure manual pump station
Aluminum alloy ultra-high pressure manual pump station
Super high pressure electric hydraulic pump station
Aluminum alloy ultra-high pressure pumping station, working frequently
The unit price does not include tax, please communicate with each other for details.
Guaranteed delivery time
If we are 45 days late, you will receive your order for free. More details
Always in touch with you
We will answer any questions every day.
Secure payment in a convenient way
We will accept payment by any card
About the product
Characteristic
- Brand
Glory
- Scope of application
Widely used in the working conditions of bolt tightening and disassembly
- Model
RYLD
- Weight
15
- Working stroke
10mm
- Processing customization
No
- Bolt specification
M30
- Range of tensile force
800KN
Description
RYSD—单级液压螺栓拉伸器
最高使用压力150MPA
自动回程机构设计、发黑处理表面
不同规格的螺栓可以使用同一台拉伸器预紧和拆松，必须更换拉伸头和拨套。
基本参数（表中参数可能因为改良而变更，恕不另行通知）
|
型号 |
适用螺栓 |
最大负载 KN |
尺寸 |
行程 |
|||||
|
A |
B |
C |
D |
E |
F |
||||
|
RYSD2 |
M33 |
814 |
132 |
90 |
36 |
44 |
135 |
150 |
8 |
|
M36 |
96 |
39 |
47 |
138 |
153 |
||||
|
RYSD3 |
M39 |
989 |
150 |
110 |
42 |
42 |
136 |
156 |
10 |
|
M42 |
113 |
45 |
45 |
140 |
155 |
||||
|
M45 |
114 |
50 |
50 |
144 |
161 |
||||
|
M48 |
118 |
52 |
52 |
146 |
163 |
||||
|
RYSD4 |
M52 |
1413 |
174 |
132 |
55 |
56 |
154 |
174 |
10 |
|
M56 |
135 |
59 |
60 |
158 |
178 |
||||
|
RYSD5 |
M60 |
1649 |
198 |
143 |
64 |
64 |
165 |
183 |
12 |
|
M64 |
150 |
68 |
68 |
169 |
187 |
||||
|
M68 |
158 |
72 |
72 |
173 |
191 |
||||
|
RYSD6 |
M72 |
2131 |
222 |
165 |
76 |
76 |
184 |
207 |
12 |
|
M76 |
170 |
80 |
80 |
188 |
211 |
||||
|
RYSD7 |
M80 |
2544 |
252 |
175 |
85 |
85 |
197 |
224 |
12 |
|
M85 |
190 |
90 |
88 |
199 |
226 |
||||
|
M90 |
205 |
95 |
95 |
209 |
236 |
||||
|
RYSD8 |
M95 |
3101 |
282 |
215 |
100 |
100 |
214 |
243 |
12 |
|
M100 |
135 |
105 |
105 |
219 |
248 |
||||
|
RYSD9 |
M105 |
3793 |
318 |
240 |
110 |
110 |
224 |
254 |
12 |
注：除以上规格以外，可以根据客户的特殊要求定做。
