5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads
5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads
5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads
5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads
5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads

5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads

0.0
0 sold.
Minimum quantity is: 2 pcs

Price from:

235,103 so'm

Guaranteed delivery time

If we are 45 days late, you will receive your order for free. More details

Always in touch with you

We will answer any questions every day.

Secure payment in a convenient way

We will accept payment by any card

5050 High-power UVC Lamp Beads 254nm265nm275nm255nm Multiple Strings and Package Sterilization Lamp Beads

About the product

Characteristic

Origin

Shenzhen

Working current

700/1400/2800

Working voltage

5-7/10-13

Power

5-20W

Item no

5050 four-core UVC LED

Brand

Yingfeng

Overall dimensions

5050

Model

5050 four-core UVC LED

Bracket material

Aluminum nitride + quartz glass

Whether to import

No

Thermal resistance

2.5

Order number

5050 four-core UVC LED

Color rendering index

90 or more

Illumination angle

120/60

Luminous efficiency

0

Chip brand

Korea/japan

Luminous surface size

5050

Color difference

5

Accelerated aging in 96 hours

1

Maximum permissible temperature

45

Light intensity/light flux

150-550mW

Main wavelength/color temperature

250-315

ESD (human mode)

2000

1000 hours regular aging

98

There are licensable private brands

Yes

Description

undefined

产品参数



产品型号

峰值波长

(nm)

辐射功率

(mW)

辐射强度

(mW/cm2) 1cm

电流

(mA)

电压

(V)

角度

(0°)

半波宽

(nm)
HYE50P30F250AG-D4E 250-260 150-180 25 1400 5-7 120 11
HYE50P30F260AG-D4E 260-270 180-220 24 1400 5-7 120 11
HYE50P30F270AG-D4E 270-280 180-220 24 1400 5-7 120 11
HYE50P30F310AG-D4E 305-315 300-350 33 1400 5-7 120 13
HYE50P45F250AG-D4E 250-260 400-500 54 2800 5-7 120 11
HYE50P45F310AG-D4E 305-315 450-550 60 2800 5-7 120 13
HYE50P30F250AG-D4A 250-260 150-180 25 700 10-13 120 11
HYE50P30F260AG-D4A 260-270 180-220 24 700 10-13 120 11
HYE50P30F270AG-D4A 270-280 180-220 24 700 10-13 120 11
HYE50P30F310AG-D4A 305-315 300-350 33 700 10-13 120 13
HYE50P45F250AG-D4A 250-260 400-500 54 1400 10-13 120 11
HYE50P45F310AG-D4A 305-315 450-550 60 1400 10-13 120 13
HYF50P30F250AG-X4E 250-260 150-180 39 1400 5-7 60 11
HYF50P30F260AG-X4E 260-270 180-220 52 1400 5-7 60 11
HYF50P30F270AG-X4E 270-280 180-220 52 1400 5-7 60 11
HYF50P30F310AG-X4E 305-315 300-350 83 1400 5-7 60 13
HYF50P45F250AG-X4E 250-260 400-500 115 2800 5-7 60 11
HYF50P45F310AG-X4E 305-315 450-550 128 2800 5-7 60 13
HYF50P30F250AG-X4A 250-260 150-180 39 700 10-13 60 11
HYF50P30F260AG-X4A 260-270 180-220 52 700 10-13 60 11
HYF50P30F270AG-X4A 270-280 180-220 52 700 10-13 60 11
HYF50P30F310AG-X4A 305-315 300-350 83 700 10-13 60 13
HYF50P45F250AG-X4A 250-260 400-500 115 1400 10-13 60 11
HYF50P45F310AG-X4A 305-315 450-550 128 1400 10-13 60 13

如何计算总光强



紫外线剂量是指达到一定的细菌灭活率所需要的特定波长的紫外线量:



总光强(J/m2) =照射时间(s) X UVC强度(W/m2)

辐照剂量越大，消毒效率越高。



UVC光功率越高，杀死细菌和病毒所需的时间越短，反之亦然，光功率越低，消毒所需的时间越长。



温馨提示：以上参数只供参考，可代客户开ＰＣＢ板和焊接出货，我司目前提供常规２０ｍｍ铜板，

本公司愿意为您定制个性化的产品。
