High Accuracy Apache3 Remote Control Unmanned Ship Survey Eq

About the product

Characteristic

Type

Oxygen bullet thermometer

Brand

Default items

Model

Default items

Is it imported?

No

Processing and customization

No

Description

High Accuracy Apache3 Remote Control Unmanned Ship Survey Equipment Unmanned Boat Surface Vehicle Surveying USV Boat Water

High Accuracy Apache3 Remote Control Unmanned Ship Survey Equipment Unmanned Boat Surface Vehicle Surveying USV Boat Water



Technical parameter
Hull dimension(LxWxH) 1000mm*650mm*300mm
material Macromolecule polyester carbon fiber
Weight (w/o instrurent and battery) 7kg
Maximum payload 25kg
Anti-wave & Wind 3  wind level and 2 wave level
Hull design Triple-hull vessel
Draft 10cm
indicator light Two-color light (Display positioning signal)
video 360° omnidirectional video
secure Shoal automatic reversing, millimeter-wave automatic obstacle avoidance and video inspection
go on the homeward voyage Low power automatic homing, lost contact automatic homing (short-path homing)
Protective measure Ship body equipped with anti-skid strip, safe and reliable
Dynamic type power-driven
Motor type Brushless machine
Steering type Coxless steering
Motor power Single motor Max. 700W
Motor speed Max 7000 RPM
Motor mounting mode Plug and dial design, easy to disassemble
Display screen 10 inch industrial touch screen sunlight viewable screen
Resolution 1920*1200
Android system Android 9.1
Internal memory 4GB of storage, 64GB of storage capacity
Communication frequency 800MHz/1,4GHz/2.4GHz
Communication distance Data radio conventional 2km, maximum 3km, 4G unlimited
Battery capacity 20000mAh
Service life 5 hours
Charging power 36W fast charge, charging time is 4 hours
port USB port, Nano SIM card slot, LAN port, audio interface, HDM interface, TF card maximum support 128 G8, Type-C
key Main rocker *2, secondary rocker *2, knob *2, key *8
Hull control Physical key control manual/automatic, hover control, integrated software control hull, route planning, underwater terrain data acquisition
