High Performance gps rtk surveying gnss RTK GNSS base and ro

About the product

Characteristic

Brand

Leica Geosystems

Description

Product Description

● Compact design, more productive
● Professional GNSS satellites tracked simultaneously(GPS, Glonass, Galileo, Beidou)
● Automatic data collection during centering
● It has IUM function. When the pole is tilted in 60 degrees, it still could get the right point data by automatic correct system.
● Applies WIFI connection to realize WebUI control designed to modify settings and monitor the receiver status
● Bundled Android field software brings a big change in user experience and accessibility
Detailed Images
Items
Specification







    GNSS Engine
Model
A90
GNSS board
P20
Channel
800 channels




Satellites
GPS: L1C/A, L2E, L2C, L5
GLONASS: L1C/A, L2 C/A, L3, CDMA
BeiDou: B1I, B2I, B3I,B1C, B2a,B2b, ACEBOC
Galileo: E1, E5 AltBOC, E5A, E5B, E6
NavlC (IRNSS): L5
SBAS: L1C/A, L5
QZSS: L1C/A, L1 SAIF, L1C, L2C, L5, LEX
IMU function
tilt survey 60 degree


Performance Specifications

Time to First Fix
Cold Start: ＜45 seconds
Warm Start: ＜30 seconds
Signal Re-acquisition:＜2 seconds


RTK Initialization time
Typically ＜8 seconds
RTK Initialization Reliability ＞99.9%
Position Latency: ＜20ms

Receiver Accuracy
Static post processing accuracy
Horizon: ±( 2.5 1*10"D) mm; Vertical: ±( 5 1*10"D) mm
RTK Positiong accuracy
Horizon: ±( 8 1*10"D) mm; Vertical: ±( 15 1*10"D) mm
Code different positioning accuracy
0.45m
Single point positioning
1.5m





System
Operating system
Based on Linux, support Web UI
Memory
8G ,supports extending 32GB
Voice
Multi language support
Wi-Fi
IEEE 802.11 b/g/n
Blue Tooth
V2.1 EDR/V4.1Dual,Class2
Network
4G-LTE, TE-SCDMA, CDMA(EVDO 2000), WCDMA, GSM(GPRS)

Power
7.2V 6800mAh , removable battery
over 13 hours when simultaneous use of 2 batteries


Physical
Button
1 Power Button
Indication Light
4 Indication Lights
Size
Φ156mm * H 76mm
Weight
1.2kg

I/O Interface
TNC port
connecting built-in radio antenna
5-pin lemo port
connecting external power supply and external radio
7-pin lemo port
(USB serial port): connecting PC and handheld




Environmental
Operating temperature
-30℃ to 65℃（-22°F to 149°F）
Storage temperature
-40℃ to 80℃（-40°F to 176°F）
Humidity
100% condensing
Waterproof
IP68

Shock
2m (6.56ft) pole drop
1.2m (3.94ft) free drop
Company Profile
Tianjin Unique Technology Co., Ltd. is a high-tech enterprise that specializes in researching and manufacturing high accuracy GNSS products and surveying equipment. Our products refer to many fields including GIS (geographic information system), Land Survey, Machine Control, SI (system integration), Agriculture and Auto Steering System, etc. Our aim is to provide the high-quality products and offer the best solutions and services for our customers worldwide.
